MOOG D136‑001‑007 M3000 MSC Servo Controller Module

Product Description

MOOG D136‑001‑007 is M3000 series MSC servo controller module, equipped with PowerPC processor and Profibus‑DP slave interface.

Supports multi‑axis motion control and integrated PLC function, applies to electric and hydraulic drive systems, widely used for industrial

automation equipment maintenance and spare replacement.

Technical Specifications

• Model: D136‑001‑007 (M3000 MSC)
• Processor: 32‑bit PowerPC RISC
• Memory: 4MB RAM, 4MB Flash EEPROM
• Communication: Profibus‑DP slave, CAN bus
• Cycle Time: Minimum 500µs
• Mounting: DIN 35mm rail mounting
• Programming: IEC 61131 MACS software

Key Features

• Multi‑axis high‑speed closed‑loop motion control
• Integrated PLC functionality for automation tasks
• Profibus‑DP and CAN bus communication support
• Suitable for both electric and hydraulic drive applications
• Compact DIN‑rail cabinet installation design
